Main Technical Specification: | | Spase resolution of tomogram, mkm | 150 | Object diameter, mm | 1500 | Object weight, kg | 1000 | Scope of working region, mm | 2000х2740х2320 | X-ray source - betatron (under development) | MIB-7 (TPU) | Electron energy, MeV | до 7 | Focal spot, mm | 1х0.3 | X-ray source - X-ray tube | MXR-451HP/11(COMET) | Anode voltage, kV | up 450 | Power, W | 700 or 1500 | Focal spot, mm | 0.4 or 1.0 | Detector - flat panel | XRD-1642 (PerkinElmer) | Detector size | 2048х2048 | Detector resolution, mkm | 200 | Detector - array (not mounted) | X-Scan 0.4iHE2-410 M (Detection Technology) | Number of detectors | 1024 | Detector resolution, mkm | 400 |
|
|
